Square one-piece skate PMC
Features
Reference
A.PMC 500-40
Manufacturer
ALTEC FRANCE
CAPACITÉ UNITAIRE (KG)
15000.00
POIDS UNITAIRE (KG)
10.00
EPAISSEUR (MM)
40
LONGUEUR (MM)
500
LARGEUR (MM)
500
POIGNÉES
1
Several references available, see table for specifications.
| Code | Type | Length (mm) | Useful width (mm) | Unit capacity (kg) | Unit weight (kg) |
|---|---|---|---|---|---|
| A.PMC 300-30 | Square monobloc skate - ep 30mm | 300 | 300 | 4000.00 | 2.00 |
| A.PMC 400-25 | Square monobloc skate - ep 25mm | 400 | 400 | 8000.00 | 4.00 |
| A.PMC 400-30 | Square monobloc skate - ep 30mm | 400 | 400 | 8000.00 | 5.00 |
| A.PMC 400-40 | Square monobloc skate - ep 40mm | 400 | 400 | 10000.00 | 6.00 |
| A.PMC 400-50 | Square monobloc skate - ep 50mm | 400 | 400 | 12000.00 | 10.00 |
| A.PMC 400-60 | Square monobloc skate - ep 60mm | 400 | 400 | 12000.00 | 12.00 |
| A.PMC 500-30 | Square monobloc skate - ep 30mm | 500 | 500 | 12000.00 | 7.50 |
| A.PMC 500-40 | Square monobloc skate - ep 40mm | 500 | 500 | 15000.00 | 10.00 |
| A.PMC 500-50 | Square monobloc skate - ep 50mm | 500 | 500 | 18000.00 | 12.00 |
| A.PMC 500-60 | Square monobloc skate - ep 60mm | 500 | 500 | 20000.00 | 15.00 |
| A.PMC 600-40 | Square monobloc skate - ep 40mm | 600 | 600 | 20000.00 | 14.00 |
| A.PMC 600-50 | Square monobloc skate - ep 50mm | 600 | 600 | 23000.00 | 18.00 |
| A.PMC 600-60 | Square monobloc skate - ep 60mm | 600 | 600 | 25000.00 | 21.00 |
| A.PMC 800-50 | Square monobloc skate - ep 50mm | 800 | 800 | 30000.00 | 31.00 |
| A.PMC 800-60 | Square monobloc skate - ep 60mm | 800 | 800 | 30000.00 | 38.00 |
| A.PMC 1000-50 | Square monobloc skate - ep 50mm | 1000 | 1000 | 40000.00 | 50.00 |
| A.PMC 1000-60 | Square monobloc skate - ep 60mm | 1000 | 1000 | 50000.00 | 60.00 |
| A.PMC 1000-80 | Square monobloc skate - ep 80mm | 1000 | 1000 | 70000.00 | 80.00 |
| A.BOX1PMC400 L | Box for 1 skate PMC 400-30/40/50/60 | / | / | / | 5.00 |
| A.BOX2/4PMC400 L | Box for 2 skate PMC 400-40/50/60 | / | / | / | 7.00 |
| A.BOX2PMC500 L | Box for 2 skates PMC 500-40/50/60 | / | / | / | 10.00 |
The square one-piece PMC skates, made of HDPE, are easily maneuverable thanks to rope handles providing high visibility.
More comfort for the user:
- No risk of injuries due to splinters (wood).
- No protruding angles, the edges are chamfered and beveled.
Compact material regardless of weather conditions, increased longevity compared to wood, easy cleaning.
Calculation to determine the capacity for 4 stabilizers:
(2/3 of the crane's weight + crane's load capacity) ÷2 = capacity per skate
For more information, see PMC product sheet. For other features, please contact us.
Square one-piece skate PMC
Reference
A.PMC 500-40
Manufacturer
ALTEC FRANCE
CAPACITÉ UNITAIRE (KG)
15000.00
POIDS UNITAIRE (KG)
10.00
EPAISSEUR (MM)
40
LONGUEUR (MM)
500
LARGEUR (MM)
500
POIGNÉES
1
| Code | Type | Length (mm) | Useful width (mm) | Unit capacity (kg) | Unit weight (kg) |
|---|---|---|---|---|---|
| A.PMC 300-30 | Square monobloc skate - ep 30mm | 300 | 300 | 4000.00 | 2.00 |
| A.PMC 400-25 | Square monobloc skate - ep 25mm | 400 | 400 | 8000.00 | 4.00 |
| A.PMC 400-30 | Square monobloc skate - ep 30mm | 400 | 400 | 8000.00 | 5.00 |
| A.PMC 400-40 | Square monobloc skate - ep 40mm | 400 | 400 | 10000.00 | 6.00 |
| A.PMC 400-50 | Square monobloc skate - ep 50mm | 400 | 400 | 12000.00 | 10.00 |
| A.PMC 400-60 | Square monobloc skate - ep 60mm | 400 | 400 | 12000.00 | 12.00 |
| A.PMC 500-30 | Square monobloc skate - ep 30mm | 500 | 500 | 12000.00 | 7.50 |
| A.PMC 500-40 | Square monobloc skate - ep 40mm | 500 | 500 | 15000.00 | 10.00 |
| A.PMC 500-50 | Square monobloc skate - ep 50mm | 500 | 500 | 18000.00 | 12.00 |
| A.PMC 500-60 | Square monobloc skate - ep 60mm | 500 | 500 | 20000.00 | 15.00 |
| A.PMC 600-40 | Square monobloc skate - ep 40mm | 600 | 600 | 20000.00 | 14.00 |
| A.PMC 600-50 | Square monobloc skate - ep 50mm | 600 | 600 | 23000.00 | 18.00 |
| A.PMC 600-60 | Square monobloc skate - ep 60mm | 600 | 600 | 25000.00 | 21.00 |
| A.PMC 800-50 | Square monobloc skate - ep 50mm | 800 | 800 | 30000.00 | 31.00 |
| A.PMC 800-60 | Square monobloc skate - ep 60mm | 800 | 800 | 30000.00 | 38.00 |
| A.PMC 1000-50 | Square monobloc skate - ep 50mm | 1000 | 1000 | 40000.00 | 50.00 |
| A.PMC 1000-60 | Square monobloc skate - ep 60mm | 1000 | 1000 | 50000.00 | 60.00 |
| A.PMC 1000-80 | Square monobloc skate - ep 80mm | 1000 | 1000 | 70000.00 | 80.00 |
| A.BOX1PMC400 L | Box for 1 skate PMC 400-30/40/50/60 | / | / | / | 5.00 |
| A.BOX2/4PMC400 L | Box for 2 skate PMC 400-40/50/60 | / | / | / | 7.00 |
| A.BOX2PMC500 L | Box for 2 skates PMC 500-40/50/60 | / | / | / | 10.00 |
Questions & Answers
How do I calculate the capacity of a stack pads?
There are two ways of calculating the capacity of the monobloc skid depending on the number of outriggers on the crane: - For two outriggers: 2/3 of the unladen weight + maximum load capacity = capacity in kg/skid | - For four outriggers: (2/3 of the unladen weight + maximum load capacity)/2 = capacity in kg of the skid. Example for a 50T crane with a load capacity of 10T on 4 outriggers: (50T x 2)/3 = 33330kg + 10T = 43330 /2 = 22T per skid.
Are there different sizes of stack pads?
Yes, there are square, round and notched one-piece skids.
Are there storage boxes for stack padss?
Yes, we have storage boxes for one or two skates. Please note that these storage boxes correspond to one skate size. See our technical data sheet for more information.
Is it possible to have a central print?
Yes, on request, in which case the diameter and thickness of the print must be supplied.
Is it possible to have special dimensions?
Yes, on request
What material are stack pads made from?
They are made of HDPE (high-density polyethylene)
